4G LTE Cat 1 tracker for advanced applications with high capacity backup battery and external antennas.

Reliable 4G connection with fallback to 2G network ensures wide-ranging coverage of your fleet management needs. This model uses a separate module to gather GNSS data and has dual-channel, L1 + L5 support. Tachograph live data reading via K-Line, Tacho CAN or FMS connections for everyday driver management and fleet efficiency. CAN DATA READING FROM HEAVY VEHICLES AND SPECIAL MACHINERY

Read J1939 data that includes standard CAN FMS from heavy vehicles like trucks and raw J1939 data from special machinery, such as construction cranes or electric buses. Possibility to connect to CAN line with multiple nodes.

Properties

• FMC650-MBX50L MeiG SLM320-PE2C,
• FMC650-MCX50: MeiG SLM320-L16A;
• LTE (CaT1) / 2G (GSM / GPRS);
• GNSS;
• GPS, GLONASS, GALILEO, BEIDOU, QZSS;
• Receiver
• L1 and L5 dual-band GNSS receiver;
• Tracking sensitivity -165 dBM;
• Position Accuracy < 2.5 m CEP;
• Hot start 1.5 s;
• Warm start < 25 s;
• Cold start < 32 s;
• LTE Cat 1, GSM;
• 2G bands;
• FMC650-MBX50: B2/B3/B5/B8;
• FMC650-MCX50: B2/B3/B5/B8;
• 4G LTE bands;
• FMC650-MBX50: LTE-FDD: B1/B3/B7/B8/B20/B28;
• LTE-TDD: B38/B40/B41;
• FMC650-MCX50:
• LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28;
• LTE-TDD: B40;

Data transfer

• LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL);
• LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL);
• GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL);
• Data support SMS (text/data);

Transmit power

• Class 4 for GSM850/900: 31±2dBm;
• Class 1 for GSM1800/1900: 30±2dBm;
• Class 3 for LTE-TDD: 23±3dBm;
• Class 3 for LTE-FDD: 23±3dBm;
• Bluetooth LE: up to 6.64 dBm;

Power

• Input voltage range 8–32 V DC with overvoltage (compatible with pulse 5a and pulse 5b) and reverse polarity protection;
• Internal Back-up battery 550 mAh Ni-Mh, 8.4 V battery;
• Internal fuse 3A, 125V;
• 2 W max. Current consumption at 12 V;
• GPRS: average 60 mA;
• Nominal: average 45 mA (with no load);
• GNSS sleep: average 32 mA;
• Deep Sleep: average 4 mA;
• Online Deep Sleep: average 11 mA;
• Full Load/Peak: <0.25A Max;
• 2 W max. Current consumption at 24 V;
• GPRS: average 35 mA;
• Nominal: average 24 mA (with no load);
• GNSS sleep: average 17 mA;
• Deep Sleep: average 2,9 mA;
• Online Deep Sleep: average 7 mA;
• Specification 5.0 + LE;
• Temperature and Humidity sensor, Universal BLE sensors support;
• Dimensions 104.1*76.8 *31.5 mm;
• Weight 197 g.;
• Operating temperature (without battery) -40 °C to +85 °C;
• Storage temperature (without battery) -40 °C to +85 °C;
• Operating humidity 5% to 95% non-condensing;
• Storage temperature (with battery) -20 °C to +45 °C;
• Ingress Protection Rating IP41;
• Battery storage temperature -20 °C to +45°C;
• K-line 1;
• GNSS antenna;
• External High Gain (L1+L5);
• Cellular antenna;
• External High Gain;
• USB;
• 2.0 Mini-USB – device can be powered by USB for easier device configuration;
• LED indication;
• 2 status LED lights;
• SIM 2x SIM Card (Dual-SIM) or 1x eSIM;
• Memory 16 MB internal flash memory and external Micro SD card up to 32GB;
• Switchable CAN terminators;
• Supported on CAN1 and CAN2 lines;

Scenarios

• Green/Eco Driving, Over Speeding detection, Jamming detection, Excessive Idling detection, Towing detection, Crash detection, Immobilizer, iButton Read Notification, Auto Geofencing, Manual Geofencing, Trip detection, Odometer, Fuel counter, GNSS Unplug Detection, DDD download and Tacho online data, Offline tracking;

Supported peripherals

• Garmin, RFID RS232, RFID 1-Wire, iButton 1-Wire, Temperature 1-Wire, LV-CAN200, CAN FMS (J1939, J1708), K-line data, Continental tire pressure measurement sensor, Iridium SBD (Iridium Edge/TSM232), Carrier freezer, Log Mode, NMEA, TCP ASCII/Binary, Temperature and humidity sensor, Universal BLE sensors support;

Sleep modes

• GPS Sleep, Online Deep Sleep, Deep Sleep;
• Configuration and firmware update;
• FOTA Web, FOTA, Teltonika Configurator;
• Configuration, Events, DOUT control, Debug;
• Configuration, DOUT control, Debug;
• Time Synchronization GNSS, NITZ, NTP;

Fuel monitoring

• LLS (Analog), Digital LLS (RS232, RS485), LV-CAN200, CAN FMS, Ultrasonic level sensor;
• Ignition detection;
• Digital Input, Accelerometer, External Power Voltage;
• RS232 Modes;
• Log Mode, NMEA, LLS, LCD, RFID HID/MF7, Garmin FMI, TCP ASCII/Binary, TCP ASCII/Binary (Buffered), Rec to LCD, Atol Tachograph, UL202-2 Fuel Sensor, Iridium Edge/TSM232 Satellite backup, Carrier Freezer;

RS485 Modes

• Silent, Log Mode, NMEA, LLS, TCP ASCII/Binary, TCP ASCII/Binary (Buffered);

Certification & approvals

• Class 4 for GSM850/900: 31±2dBm;
• Class 1 for GSM1800/1900: 30±2dBm;
• Class 3 for LTE-TDD: 23±3dBm;
• Class 3 for LTE-FDD: 23±3dBm;
• Bluetooth LE: up to 6.64 dBm;

Set of equipment

• GPS tracker Teltonika FMC 650;
• Server/SIM card for an additional fee;
• Directions for use in English  language;


Warranty: 24 months;
Fast delivery.
